Name: SCR03AM-16
Brand: Surge Components
SKU: SCR03AM-16
Availability: OutOfStock

Part No	ITSM_Max @ f = 50Hz (A)	IT(RMS)_Max (A)	TJ_Max (°C)	IGT_I_Max (mA)	VDRM_Min (V)	Package
SX080K	80 A	8 A	110°C	0.2 mA	800 V	TO-252
SX075K	120 A	12 A	110°C	0.2 mA	800 V	TO-252
SX075F	120 A	12 A	110°C	0.2 mA	800 V	TO-220F
SX040Q	40 A	4 A	125°C	0.2 mA	600 V	TO-126
SX040K	40 A	4 A	125°C	0.2 mA	600 V	TO-252
SX020V	20 A	2 A	125°C	0.2 mA	600 V	SOT-223
SX020U	20 A	2 A	125°C	0.2 mA	600 V	TO-92
SX020Q	20 A	2 A	125°C	0.2 mA	600 V	TO-126
SX020N2	20 A	2 A	125°C	0.2 mA	600 V	SOT-89-2L
SX017W	15 A	1 A	110°C	0.2 mA	1800 V	SOT-223-2L
SX017N2	15 A	1 A	110°C	0.2 mA	1800 V	SOT-89-2L
SX016K	55 A	6 A	110°C	0.2 mA	1600 V	TO-252
SX014W	25 A	1.25 A	110°C	0.2 mA	1250 V	SOT-223-2L
SX014V	25 A	1.25 A	110°C	0.2 mA	1250 V	SOT-223
SX014CR	25 A	1.25 A	110°C	0.2 mA	1250 V	TO-92CR
SX013W	17 A	1 A	110°C	0.2 mA	1200 V	SOT-223-2L
SX012V	20 A	1.25 A	110°C	0.2 mA	1200 V	SOT-223
SX012U	20 A	1.25 A	110°C	0.2 mA	1200 V	TO-92
SX012N2	20 A	1.25 A	110°C	0.2 mA	1200 V	SOT-89-2L
SX011V	12 A	1 A	125°C	0.2 mA	800 V	SOT-223
SX011U	12 A	1 A	125°C	0.2 mA	800 V	TO-92
SX011N2	12 A	1 A	125°C	0.2 mA	800 V	SOT-89-2L
SX008V	8 A	0.8 A	125°C	0.2 mA	800 V	SOT-223
SX008U	8 A	0.8 A	125°C	0.2 mA	800 V	TO-92
SX008NP2	8 A	0.8 A	125°C	0.2 mA	800 V	SOT-89-2L _NP2
SX008N2	8 A	0.8 A	125°C	0.2 mA	800 V	SOT-89-2L
SX008L	8 A	0.8 A	125°C	0.2 mA	800 V	SOT-23-3L
SX007U	8 A	0.8 A	125°C	0.12 mA	500 V	TO-92
STYN80H-1200SJ	1000 A	126 A	150°C	Oct-80 mA	1200 V	TO-247J
SR0805F	80 A	8 A	125°C	0.2 mA	600 V	TO-220F
SR0405K	40 A	4 A	125°C	0.2 mA	600 V	TO-252
SR0405H	40 A	4 A	125°C	0.2 mA	600 V	TO-251
SR0205K	20 A	2 A	125°C	0.2 mA	600 V	TO-252
SMCR100-8	12 A	1 A	125°C	0.2 mA	800 V	TO-92
SHX015W	15 A	1.5 A	110°C	3 mA	1600 V	SOT-223-2L
SCT840A	500 A	40 A	125°C	35 mA	800 V	TO-220A
SCT825E	320 A	25 A	125°C	20 mA	800 V	TO-263
SCT825A	320 A	25 A	125°C	20 mA	800 V	TO-220A
SCT820C	250 A	20 A	125°C	15 mA	800 V	TO-220C
SCT816K	150 A	16 A	125°C	15 mA	800 V	TO-252
SCT816F	150 A	16 A	125°C	15 mA	800 V	TO-220F
SCT816E	150 A	16 A	125°C	15 mA	800 V	TO-263
SCT816A	150 A	16 A	125°C	15 mA	800 V	TO-220A
SCT812K	140 A	12 A	125°C	15 mA	800 V	TO-252
SCT812E	140 A	12 A	125°C	15 mA	800 V	TO-263
SCT640F	500 A	40 A	125°C	35 mA	600 V	TO-220F
SCT640A	500 A	40 A	125°C	35 mA	600 V	TO-220A
SCT625F	320 A	25 A	125°C	20 mA	600 V	TO-220F
SCT625C	320 A	25 A	125°C	20 mA	600 V	TO-220C
SCT625A	320 A	25 A	125°C	20 mA	600 V	TO-220A
SCT620F	250 A	20 A	125°C	15 mA	600 V	TO-220F
SCT620A	250 A	20 A	125°C	15 mA	600 V	TO-220A
SCT616K	150 A	16 A	125°C	15 mA	600 V	TO-252
SCT616H	150 A	16 A	125°C	15 mA	600 V	TO-251
SCT616F	150 A	16 A	125°C	15 mA	600 V	TO-220F
SCT612TF	140 A	12 A	125°C	5 mA	600 V	TO-220F
SCT612TC	140 A	12 A	125°C	5 mA	600 V	TO-220C
SCT612A	140 A	12 A	125°C	15 mA	600 V	TO-220A
SCT610K	110 A	10 A	125°C	10 mA	600 V	TO-252
SCT610F	110 A	10 A	125°C	10 mA	600 V	TO-220F
SCT610C	110 A	10 A	125°C	10 mA	600 V	TO-220C
SCT1690IS	1000 A	90 A	125°C	Oct-80 mA	1600 V	ITO-247
SCT1690CS	1000 A	90 A	125°C	Oct-80 mA	1600 V	TO-247S
SCT1675Z	1000 A	75 A	125°C	10~80 mA	1600 V	TO-3P
SCT1675SJ	900 A	75 A	125°C	Oct-80 mA	1600 V	TO-247J
SCT1655Z	600 A	55 A	125°C	Oct-80 mA	1600 V	TO-3P
SCT1655SJ	600 A	55 A	125°C	Oct-80 mA	1600 V	TO-247J
SCT1640Z	400 A	40 A	125°C	45 mA	1600 V	TO-3P
SCT1630A	300 A	30 A	125°C	40 mA	1600 V	TO-220A
SCT1625E	280 A	25 A	125°C	40 mA	1600 V	TO-263
SCT1625A	280 A	25 A	125°C	40 mA	1600 V	TO-220A
SCT16130IS	1500 A	130 A	125°C	20-80 mA	1600 V	ITO-247
SCT16110IS	1100 A	110 A	125°C	Oct-80 mA	1600 V	ITO-247
SCT16110CS	1100 A	110 A	125°C	Oct-80 mA	1600 V	TO-247S
SCT1608K	80 A	8 A	125°C	15 mA	1600 V	TO-252
SCT151K-800R	120 A	12 A	125°C	15 mA	800 V	TO-252
SCT151K-650R	120 A	12 A	125°C	15 mA	650 V	TO-252
SCT151F-650R	120 A	12 A	125°C	15 mA	650 V	TO-220F
SCT151C-800R	120 A	12 A	125°C	15 mA	800 V	TO-220C
SCT151C-650R	120 A	12 A	125°C	15 mA	650 V	TO-220C
SCT1275Z	800 A	75 A	125°C	Oct-80 mA	1200 V	TO-3P
SCT1275SJ	800 A	75 A	125°C	Oct-80 mA	1200 V	TO-247J
SCT1255Z	700 A	55 A	125°C	50 mA	1200 V	TO-3P
SCT1255SJ	700 A	55 A	125°C	50 mA	1200 V	TO-247J
SCT1240Z	500 A	40 A	125°C	45 mA	1200 V	TO-3P
SCT1240CH	500 A	40 A	150°C	45 mA	1200 V	TO-220C
SCT1240A	500 A	40 A	125°C	45 mA	1200 V	TO-220A
SCT1231C	370 A	30 A	125°C	40 mA	1200 V	TO-220C
SCT1225F	320 A	25 A	125°C	40 mA	1200 V	TO-220F
SCT1225E	320 A	25 A	125°C	40 mA	1200 V	TO-263
SCT1225C	320 A	25 A	125°C	40 mA	1200 V	TO-220C
SCT1225A	320 A	25 A	125°C	40 mA	1200 V	TO-220A
SCT1208K	85 A	8 A	125°C	15 mA	1200 V	TO-252
SCT1208C	85 A	8 A	125°C	15 mA	1200 V	TO-220C
SCR03AM-16	25 A	1.25 A	110°C	0.2 mA	1250 V	SOT-223
